Swing Check Valve - Image 1
Click to enlarge
Inline Check Valve (Control Devices)
Inline Check Valve (Control Devices)
Back to products
Check Valve - Female - Female
Check Valve - Female - Female

Swing Check Valve

Please see below for product description and specs.
Category:
Description
  • Bronze Construction
  • Operating Temp. 200° F
  • Max. Pressure 150 psi
  • Full flow and can be installed vertically or horizontally
  • Recommended for preventing back flow
Model Size
SCY-50 1/2”
SCY-75 3/4”
SCY-10 1”
SCY-12 1 1/4”
SCY-15 1 1/2”
SCY-20 2”
Additional information
Size

1/2”

,

3/4”

,

1”

,

1 1/4”

,

1 1/2”

,

2”
